TENAC™ Application cases

Fuel pump module

It is a part that is mounted on the fuel tank of a vehicle and has a built-in pump and fuel filter in the lower case, and sends purified fuel from the upper flange to the engine.
The main parts are made of POM resin, which has excellent fuel resistance.

Products

TENAC™

Features

・Excellent fuel resistant property.
・Excellent creep resistance.

Inside door handle / case

・Achieves the UV resistance and chemical resistance required for automobile interior parts without painting.
・Changes in the mechanical properties and color tone due to heat aging and UV irradiation have cleared the standards of each OEM.
・It complies with OEM in-vehicle environmental standards (reduction of volatile components), which are becoming stricter year by year.

Products

TENAC™

Grades

TENAC™-C Z4513:Medium viscosity, low formaldehyde emisson, UV resistant copolymer grade
TENAC™-C ZM413:Medium viscosity, low formaldehyde emisson , UV resistant, metallic appearance copolymer grade

Features

・Low VOC (Volatile Organic Compound) property of the highest level in the industry.
・Excellent UV resistance.
・The metallic appearance grade enables high designed product surface without painting.

Through anchor

The through anchor is installed on the center pillar, and the metal parts are coverd with POM resin to maintain the slidability with the seat belt made from polyester.
In addition, high-viscosity UV-resistant homopolymer grade 3013A is used because it is required to have impact resistance in the automobile crash and UV resistance because it is an interior part.

Products

TENAC™

Grades

TENAC™ 3013A:Ultra-high viscosity UV resistant homopolymer grade

Features

・UV resistance
・Excellent imapct strength.

Seat-belt press button

・It has the high UV resistance and low formaldehyde emisson properties required for automobile interior parts.
・It has excellent impact strength and is not easily damaged even in an emergency.

Products

TENAC™

Features

・Industry's highest level of low VOC (volatile organic compound) performance
・UV resistance
・Impact strength

Motor gear

Since the gears used in the motors that window lifters, wipers, seats, etc. are required to have high durability, high-viscosity homopolymers are mainly used.

Products

TENAC™

Features

・Excellent durability.
・Excellent creep property.
・Weight reduction is possible by replacing metal with POM resin.

Window regulator(Carrier plate)

POM is often used for window regulators (wire type), which are elevating devices for window glass, because of their excellent slidability and durability.
The carrier plate is made from ultra high viscosity homopolymer, which has superior fatigue resistance and high creep resistance,because it supports the window glass and receives a long-term load.

Products

TENAC™

Features

・Excellent durability
・Superior fatigue resistance, excellent creep property
・Weight reduction is possible by replacing metal with POM resin.

Door roller

Door roller opens and closes the sash smoothly.
In recent years, sashes have become heavier due to improved heat insulation and the use of double glazing.
Due to the increased load on the door roller, TENAC™ ultra-high viscosity grades are used for its excellent durability.

Products

TENAC™

Grades

・TENAC™ MG210: Ultra-high viscosity and high durability homopolymer grade
・TENAC™ 2010: Ultra-high viscosity homopolymer grade

Features

・Excellent creep property
・Low friction and wear for slinding metal

Printer gear

Gears transmit torque and rotation to the meshing gears by rotating around an axis.
The performance required for resin gears is rigidity, durability, slidability and quietness, and static and dynamic dimensional accuracy, and
TENAC™ has a lineup of numerous grades that meet the required characteristics of each.

Products

TENAC™

Grades

・ LZ750
・High stiffness / high precision copolymer grade NS556;
Inorganic filler reinforced grade that achieves both high stiffness and high precision
・High flowability and excellent slidability copolymer grades, LZ750 and LX750 ;
These two grades are based on the high-performance copolymer HC750, and different sliding agents are used for these grades.

Features

・Good slidability
・Highly precision moldability

Printer mechanical parts
(TENAC™)

・There are wide variety of mechanical parts for printers.
Typical items are shafts, bearings, arms, rollers, cams, etc.
・These products are required to have little change in performance over a long period of time.
・Rigidity and wearability are required for shafts and bearings to maintain the hole diameter, and resistance to deformation during repeated fatigue is required for arms and cams.

Products

TENAC™

Grades

・High-performance copolymer grade, HC750, HC450 ;
These polyacetal resins balances the mechanical properties of homopolymer and thermal resistance of copolymer.
・High flowability and Excellent slidability copolymer grades, LZ750 and LX750 ;
These two grades are based on the high-performance copolymer, HC750, and different sliding agents are used for these grades.

Features

・TENAC™ is a material with excellent durability, fatigue and slidability as well as mechanical properties.
・In particular, HC series , which has both the good points of homopolyner and copolymer, are the material suitable for mechanical parts.
・LZ and LX series, which has a sliding prescription based on HC series, has excellent sliding performance as well as mechanical properties.
・Due to its excellent flowability, it can be molded to thin products.

Conductive bearing

By adding various conductive carbon to non-conductive plastic, it is possible to replace electrical contact parts and ground parts that were previously metal.
It is superior in terms of productivity and cost because parts can be manufactured only by molding without secondary processing.

Products

TENAC™

Grades

・TENAC™ C-TFC77, TFC84
・Conductive copolymer grade

Features

・All grades have excellent conductivity with a volume resistance of 100 to 101Ωcm.
・TFC77 has extremely stable conductivity and slidability.
・TFC84 has stable conductivity and excellent toughness.

Infusion pump guide

・Infusion pumps are required not only to deliver the required amount of liquid stably over a long period of time and to reduce the size.
・Since the liquid feed part is always in contact with the medical tube, this part is required to have abrasion resistance.
Therefore, TENAC™ high sliding grade is applied to these parts.

Products

TENAC™

Grades

High sliding performance grade
For many years, Asahi Kasei has pursued the highest level of friction and wear characteristics and mechanical properties, and has provided the TENAC™ high sliding grade to the market.
We propose the optimum grade in combination with the counter material.

Features

・Dimensional stability
・Durability
・High load slidability

Lancet

・Lancet is used for micro blood sampling such as blood glucose measurement.
・TENAC™ is used from the viewpoint of injection moldability and good puncture property.

Products

TENAC™

Grades

High flow homopolymer grade

Features

・High flowability
・Antistatic property
・Low warpage deformability
・High crystallization rate

Fuel pump module

It is a part that is mounted on the fuel tank of a vehicle and has a built-in pump and fuel filter in the lower case, and sends purified fuel from the upper flange to the engine.
The main parts are made of POM resin, which has excellent fuel resistance.

Products

TENAC™

Features

・Excellent fuel resistant property.
・Excellent creep resistance.

Inside door handle / case

・Achieves the UV resistance and chemical resistance required for automobile interior parts without painting.
・Changes in the mechanical properties and color tone due to heat aging and UV irradiation have cleared the standards of each OEM.
・It complies with OEM in-vehicle environmental standards (reduction of volatile components), which are becoming stricter year by year.

Products

TENAC™

Grades

TENAC™-C Z4513:Medium viscosity, low formaldehyde emisson, UV resistant copolymer grade
TENAC™-C ZM413:Medium viscosity, low formaldehyde emisson , UV resistant, metallic appearance copolymer grade

Features

・Low VOC (Volatile Organic Compound) property of the highest level in the industry.
・Excellent UV resistance.
・The metallic appearance grade enables high designed product surface without painting.

Through anchor

The through anchor is installed on the center pillar, and the metal parts are coverd with POM resin to maintain the slidability with the seat belt made from polyester.
In addition, high-viscosity UV-resistant homopolymer grade 3013A is used because it is required to have impact resistance in the automobile crash and UV resistance because it is an interior part.

Products

TENAC™

Grades

TENAC™ 3013A:Ultra-high viscosity UV resistant homopolymer grade

Features

・UV resistance
・Excellent imapct strength.

Seat-belt press button

・It has the high UV resistance and low formaldehyde emisson properties required for automobile interior parts.
・It has excellent impact strength and is not easily damaged even in an emergency.

Products

TENAC™

Features

・Industry's highest level of low VOC (volatile organic compound) performance
・UV resistance
・Impact strength

Motor gear

Since the gears used in the motors that window lifters, wipers, seats, etc. are required to have high durability, high-viscosity homopolymers are mainly used.

Products

TENAC™

Features

・Excellent durability.
・Excellent creep property.
・Weight reduction is possible by replacing metal with POM resin.

Window regulator(Carrier plate)

POM is often used for window regulators (wire type), which are elevating devices for window glass, because of their excellent slidability and durability.
The carrier plate is made from ultra high viscosity homopolymer, which has superior fatigue resistance and high creep resistance,because it supports the window glass and receives a long-term load.

Products

TENAC™

Features

・Excellent durability
・Superior fatigue resistance, excellent creep property
・Weight reduction is possible by replacing metal with POM resin.

Door roller

Door roller opens and closes the sash smoothly.
In recent years, sashes have become heavier due to improved heat insulation and the use of double glazing.
Due to the increased load on the door roller, TENAC™ ultra-high viscosity grades are used for its excellent durability.

Products

TENAC™

Grades

・TENAC™ MG210: Ultra-high viscosity and high durability homopolymer grade
・TENAC™ 2010: Ultra-high viscosity homopolymer grade

Features

・Excellent creep property
・Low friction and wear for slinding metal

Printer gear

Gears transmit torque and rotation to the meshing gears by rotating around an axis.
The performance required for resin gears is rigidity, durability, slidability and quietness, and static and dynamic dimensional accuracy, and
TENAC™ has a lineup of numerous grades that meet the required characteristics of each.

Products

TENAC™

Grades

・ LZ750
・High stiffness / high precision copolymer grade NS556;
Inorganic filler reinforced grade that achieves both high stiffness and high precision
・High flowability and excellent slidability copolymer grades, LZ750 and LX750 ;
These two grades are based on the high-performance copolymer HC750, and different sliding agents are used for these grades.

Features

・Good slidability
・Highly precision moldability

Printer mechanical parts
(TENAC™)

・There are wide variety of mechanical parts for printers.
Typical items are shafts, bearings, arms, rollers, cams, etc.
・These products are required to have little change in performance over a long period of time.
・Rigidity and wearability are required for shafts and bearings to maintain the hole diameter, and resistance to deformation during repeated fatigue is required for arms and cams.

Products

TENAC™

Grades

・High-performance copolymer grade, HC750, HC450 ;
These polyacetal resins balances the mechanical properties of homopolymer and thermal resistance of copolymer.
・High flowability and Excellent slidability copolymer grades, LZ750 and LX750 ;
These two grades are based on the high-performance copolymer, HC750, and different sliding agents are used for these grades.

Features

・TENAC™ is a material with excellent durability, fatigue and slidability as well as mechanical properties.
・In particular, HC series , which has both the good points of homopolyner and copolymer, are the material suitable for mechanical parts.
・LZ and LX series, which has a sliding prescription based on HC series, has excellent sliding performance as well as mechanical properties.
・Due to its excellent flowability, it can be molded to thin products.

Conductive bearing

By adding various conductive carbon to non-conductive plastic, it is possible to replace electrical contact parts and ground parts that were previously metal.
It is superior in terms of productivity and cost because parts can be manufactured only by molding without secondary processing.

Products

TENAC™

Grades

・TENAC™ C-TFC77, TFC84
・Conductive copolymer grade

Features

・All grades have excellent conductivity with a volume resistance of 100 to 101Ωcm.
・TFC77 has extremely stable conductivity and slidability.
・TFC84 has stable conductivity and excellent toughness.

Infusion pump guide

・Infusion pumps are required not only to deliver the required amount of liquid stably over a long period of time and to reduce the size.
・Since the liquid feed part is always in contact with the medical tube, this part is required to have abrasion resistance.
Therefore, TENAC™ high sliding grade is applied to these parts.

Products

TENAC™

Grades

High sliding performance grade
For many years, Asahi Kasei has pursued the highest level of friction and wear characteristics and mechanical properties, and has provided the TENAC™ high sliding grade to the market.
We propose the optimum grade in combination with the counter material.

Features

・Dimensional stability
・Durability
・High load slidability

Lancet

・Lancet is used for micro blood sampling such as blood glucose measurement.
・TENAC™ is used from the viewpoint of injection moldability and good puncture property.

Products

TENAC™

Grades

High flow homopolymer grade

Features

・High flowability
・Antistatic property
・Low warpage deformability
・High crystallization rate

LEONA™ Application cases

End plate

Component parts for battery module.

Products

LEONA™

Grades

SN series; SN11B and etc.
GF reinforced, non-halogenated flame retardancy, V-0

Features

・Moldability
・Laser printability
・Strength
・Toughness
・Electrical characteristics (CTI)
・Heat resistance

Cylinder head cover

Privent oil splash from engine

Products

LEONA™

Grades

14G33
Excellent moldability/secondary workability and mechanical property

Features

40% lighter compared with aluminum

Engine mount bracket

Braket of the anti-vibration device attaching to the engine unit

Products

LEONA™

Grades

14G50

Features

・Heat resistance
・High strength / high stiffness
・Fatigue resistance

Chain guide shoe

Support shoe parts for automobile engine timing chains

Products

LEONA™

Grades

1442/1542
By optimally dispersing lubricant, excellent low friction and wear resistance together with mechanical properties and moldability of general PA66 resin.

Features

・Low friction, low wear
・High heat resistance
・standard and high molecular weight grade available

Timing chain case

Keep chain clean by preventing from water/dust.

Products

LEONA™

Grades

SV104
The special polymer design of LEONA™ SV series enhances the damping effect of vibration and sound compared to general PA66. Blending glass fiber can improve its strength and rigidity higher.

Features

・High attenuation performance
・High strength
・High heat resistance

Water / oil pump

Oil pumps for engines, brakes, etc.
Cooling pumps for batteries, and etc.

Products

LEONA™

Grades

BG230

Features

・Uses plant-derived materials
・Low water absorption
・Laser welding

Water pipe

Engine cooling water circulation pipe

Products

LEONA™

Grades

53G33
・Low water absorption, GF33% reinforced grade
・Low water absorption provides excellent hydrolysis resistance and calcium chloride resistance

Features

・Heat resistance
・Hydrolysis resistance
・Calcium chloride resistance
・Moldability (molding of bent pipe)

Door mirror base

Highly estetic and stiffer door mirror base to check sides and rear view.

Products

LEONA™

Grades

91G60, 90G33
Excellent balance of high stiffness, good appearance, weatherability, and easy moldability.

Features

・Good appearance
・Weatherability
・High stiffness
・Easy moldability

Rear view mirror bracket

Bracket holding the mirror to check the rear view

Products

LEONA™

Grades

SG104、SG105
High stiffness, good appearance, and easy moldability

Features

・Vibration reduction due to high stiffness
・Appearance as an interior part

Smart key housing

Key housing allows you to unlock and lock vehicle and turn the engine on and off while keeping it in your pocket or bag

Products

LEONA™

Grades

90G33
combines high rigidity, good appearance, weather resistance, and easy moldability.

Features

・Good appearance
・Weatherability
・Easy moldability

Magnet switch

A switch that opens and closes electrical contacts using an electromagnet

Products

LEONA™

Grades

・SN series, FG series: Glass fiber reinforced, UL94: V-0
・SN series: GF reinforced non-halogenated flame retardancy
・FG series: GF reinforced flame retardancy

Features

・Excellent laser printability
・Moldability
・Wear resistance
・Excellent electrical characteristics (CTI)
・Snap fit stability

Connector

For wiring electrical and electronic components

Products

LEONA™

Grades

SN series
FR series
FG series
・ SN series: GF reinforced non-halogenated flame retardancy
・ FR series: non reinforced flame retardancy
・ FG series: GF reinforced non flame retardancy

Features

・Laser printability
・Moldability
・Strength, toughness
・Electrical characteristics (CTI)
・Heat resistance

Motor end cap

Caps of various motors

Products

LEONA™

Grades

1300G
A grade with improved strength and stiffness by addition of glass fiber

Features

・Heat resistance
・Strength/toughness
・Electrical properties
・Moldability

Smartphone chassis

Smartphone internal chassis

Products

LEONA™

Grades

SG105
A grade that combines high stiffness, good appearance, and easy molding.

Features

・Good appearance
・High stiffness

Solar cell connector nut

Waterproof / dustproof nut for the moated part of the cable and connector

Products

LEONA™

Grades

FR370
Non-halogenated flame retardancy V-0

Features

・Flame retardancy
・Easy molidability

Tank for warm water toilet seat

Warm water tank for warm water toilet seat

Products

LEONA™

Grades

1300G
A grade with increased strength and stiffness by adding glass fiber

Features

・Vibration welding
・Creep resistance

Water meter case

Meter case to measuring the amount of drinking water used

Products

LEONA™

Grades

90W50 T33G0
It has fatigue resistance and excellent surface smoothness. Also supports drinking water certification standards

Features

・Fatigue resistance
・Good appearance,
・Drinking water certification

Crescent

It acts as a lock to be attached to windows and sashes with metal fittings for fittings.

Products

LEONA™

Grades

90G50 . 91G55
90G50 : A grade characterized by high stiffness, good appearance, and excellent moldability
91G55 : A grade characterized by excellent appearance, and moldability and low warpage

Features

・Good appearance/high designability
・Realized warm touch/texture and functionality with the use of plastic rather than metal.
・Elimination of such problems as shrinkage or warpage by the use of AGI molding

Solenoid valve

Controls the opening and closing of the flow in a pipe that allows fluid and gas to pass through by air pressure, pneumatic pressure, water pressure, etc.

Products

LEONA™

Grades

SH10E
A grade providing high rigidity as well as UL94:V-0 (1.5 mm)

Features

・High stiffness and flame retardancy V-0
・Improved deformation/fracture resistance at bolt tightening
・No annealing required

Gear box / Gear reducer

A speed changer that decelerates the speed obtained by the motor to generate the necessary force

Products

LEONA™

Grades

・Under development(Filler reinforcement)
・Well balanced friction& wear resistance together with High fatigue resistance performance of PA66

Features

・Friction& wear resistance
・High modulus
・Good fatigue resistance

End plate

Component parts for battery module.

Products

LEONA™

Grades

SN series; SN11B and etc.
GF reinforced, non-halogenated flame retardancy, V-0

Features

・Moldability
・Laser printability
・Strength
・Toughness
・Electrical characteristics (CTI)
・Heat resistance

Cylinder head cover

Privent oil splash from engine

Products

LEONA™

Grades

14G33
Excellent moldability/secondary workability and mechanical property

Features

40% lighter compared with aluminum

Engine mount bracket

Braket of the anti-vibration device attaching to the engine unit

Products

LEONA™

Grades

14G50

Features

・Heat resistance
・High strength / high stiffness
・Fatigue resistance

Chain guide shoe

Support shoe parts for automobile engine timing chains

Products

LEONA™

Grades

1442/1542
By optimally dispersing lubricant, excellent low friction and wear resistance together with mechanical properties and moldability of general PA66 resin.

Features

・Low friction, low wear
・High heat resistance
・standard and high molecular weight grade available

Timing chain case

Keep chain clean by preventing from water/dust.

Products

LEONA™

Grades

SV104
The special polymer design of LEONA™ SV series enhances the damping effect of vibration and sound compared to general PA66. Blending glass fiber can improve its strength and rigidity higher.

Features

・High attenuation performance
・High strength
・High heat resistance

Water / oil pump

Oil pumps for engines, brakes, etc.
Cooling pumps for batteries, and etc.

Products

LEONA™

Grades

BG230

Features

・Uses plant-derived materials
・Low water absorption
・Laser welding

Water pipe

Engine cooling water circulation pipe

Products

LEONA™

Grades

53G33
・Low water absorption, GF33% reinforced grade
・Low water absorption provides excellent hydrolysis resistance and calcium chloride resistance

Features

・Heat resistance
・Hydrolysis resistance
・Calcium chloride resistance
・Moldability (molding of bent pipe)

Door mirror base

Highly estetic and stiffer door mirror base to check sides and rear view.

Products

LEONA™

Grades

91G60, 90G33
Excellent balance of high stiffness, good appearance, weatherability, and easy moldability.

Features

・Good appearance
・Weatherability
・High stiffness
・Easy moldability

Rear view mirror bracket

Bracket holding the mirror to check the rear view

Products

LEONA™

Grades

SG104、SG105
High stiffness, good appearance, and easy moldability

Features

・Vibration reduction due to high stiffness
・Appearance as an interior part

Smart key housing

Key housing allows you to unlock and lock vehicle and turn the engine on and off while keeping it in your pocket or bag

Products

LEONA™

Grades

90G33
combines high rigidity, good appearance, weather resistance, and easy moldability.

Features

・Good appearance
・Weatherability
・Easy moldability

Magnet switch

A switch that opens and closes electrical contacts using an electromagnet

Products

LEONA™

Grades

・SN series, FG series: Glass fiber reinforced, UL94: V-0
・SN series: GF reinforced non-halogenated flame retardancy
・FG series: GF reinforced flame retardancy

Features

・Excellent laser printability
・Moldability
・Wear resistance
・Excellent electrical characteristics (CTI)
・Snap fit stability

Connector

For wiring electrical and electronic components

Products

LEONA™

Grades

SN series
FR series
FG series
・ SN series: GF reinforced non-halogenated flame retardancy
・ FR series: non reinforced flame retardancy
・ FG series: GF reinforced non flame retardancy

Features

・Laser printability
・Moldability
・Strength, toughness
・Electrical characteristics (CTI)
・Heat resistance

Motor end cap

Caps of various motors

Products

LEONA™

Grades

1300G
A grade with improved strength and stiffness by addition of glass fiber

Features

・Heat resistance
・Strength/toughness
・Electrical properties
・Moldability

Smartphone chassis

Smartphone internal chassis

Products

LEONA™

Grades

SG105
A grade that combines high stiffness, good appearance, and easy molding.

Features

・Good appearance
・High stiffness

Solar cell connector nut

Waterproof / dustproof nut for the moated part of the cable and connector

Products

LEONA™

Grades

FR370
Non-halogenated flame retardancy V-0

Features

・Flame retardancy
・Easy molidability

Tank for warm water toilet seat

Warm water tank for warm water toilet seat

Products

LEONA™

Grades

1300G
A grade with increased strength and stiffness by adding glass fiber

Features

・Vibration welding
・Creep resistance

Water meter case

Meter case to measuring the amount of drinking water used

Products

LEONA™

Grades

90W50 T33G0
It has fatigue resistance and excellent surface smoothness. Also supports drinking water certification standards

Features

・Fatigue resistance
・Good appearance,
・Drinking water certification

Crescent

It acts as a lock to be attached to windows and sashes with metal fittings for fittings.

Products

LEONA™

Grades

90G50 . 91G55
90G50 : A grade characterized by high stiffness, good appearance, and excellent moldability
91G55 : A grade characterized by excellent appearance, and moldability and low warpage

Features

・Good appearance/high designability
・Realized warm touch/texture and functionality with the use of plastic rather than metal.
・Elimination of such problems as shrinkage or warpage by the use of AGI molding

Solenoid valve

Controls the opening and closing of the flow in a pipe that allows fluid and gas to pass through by air pressure, pneumatic pressure, water pressure, etc.

Products

LEONA™

Grades

SH10E
A grade providing high rigidity as well as UL94:V-0 (1.5 mm)

Features

・High stiffness and flame retardancy V-0
・Improved deformation/fracture resistance at bolt tightening
・No annealing required

Gear box / Gear reducer

A speed changer that decelerates the speed obtained by the motor to generate the necessary force

Products

LEONA™

Grades

・Under development(Filler reinforcement)
・Well balanced friction& wear resistance together with High fatigue resistance performance of PA66

Features

・Friction& wear resistance
・High modulus
・Good fatigue resistance

XYRON™ Application cases

Inter-cell spacer

Insulator between battery cells.

Products

XYRON™

Grades

T series and 340Z
・Tracking resistance
・Hydrolysis resistance
・Acid and alkaline resistance
・Stable long-term physical properties

Features

・A material with a high degree of freedom in design suitable for the housing.
・A low specific gravity material with excellent creep characteristic, non-halogenated flame retardancy, and dimensional stability.
・Excellent thin-wall moldability, contributing to space saving and weight reduction.

Bus bar cover

Cover of conductor through which high voltage and large current flows.

Products

XYRON™

Grades

TF701, TA720, X9110

Features

・Thin-wall moldability, insulation, and heat resistance.
・Some grades have oil resistance. Easy to handle.

Fuel cell

Components for fuel cells

Products

XYRON™

Grades

500H
・Non-reinforced heat resistant grade
・Low elution performance
・Acid resistance

Features

・Low elution from resin (ions, oligomers, and etc.) to water
which is highly evaluated by customers.
・Excellent hot water resistance and acid resistance, and physical properties hardly deteriorate even when components are immersed for a long period of time.

In-vehicle camera
(lens barrel, lens spacer)

Lens barrels and lens spacers used in various cameras installed in cars

Products

XYRON™

Grades

・XP640 PPA/PPE blend + GF40%
・DG040, DG340 PPS/PPE blend + special glass filler 40%

Features

・Demonstrate high heat resistance, high strength, and high stiffness performance comparable to high heat resistance PA.
・Suppress the decrease in mechanical strength under high temperature, and reduces anisotropy of dimensional change by blending special glass filler.
・ Contribute to cost reduction of metal components by resinification.

Head-up display

Head-up display components installed in cars

Products

XYRON™

Grades

・ DG040 PPS/PPE blend + special glass filler 40%
・ 744Z PPE/PS blend (Non-reinforced)

Features

・By blending PPE with PPS, dimensional stability at high temperatures is improved, and by blending special glass filler, dimensional anisotropy is reduced.
・UL flame retardancy V-0, deflection temperature under load 135 °C, excellent balance of heat resistance, toughness and dimensional stability.

Relay block / junction box (XYRON™)

Storage case for relays, fuses, etc.

Products

XYRON™

Grades

A0210 (PA / PPE blend):. High heat resistance, high toughness, low water absorption kow dimensional change (compared to nylon material)
A0230: A0210 equivalent grade, which is using localized raw materials in the ASEAN region .
AF700 (PA / PPE blend): High heat resistance, low water absorption low dimensional change, and UL V-0

Features

-Improve changes in water absorption dimensions while maintaining the excellent heat resistance and toughness of PA.
-Can be used for advanced designs that require toughness due to our materials' strength and high toughness characterestics.
・ UL V-0 grade is also available.
-By producing hexamethylenediamine, which is the raw material for PA, in-house (the only Japanese company), we have achieved stable supply and high quality.
・ By localizing raw materials overseas, we maintain a stable supply and cost globally.

Inverter cover

Covers of various electrical equipments

Products

XYRON™

Grades

240Z、440Z
・Non-reinforced and flame retardant grades
・Excellent electrical characteristics and flame retardancy
・Hydrolysis resistance

Features

・Material with design flexibility suitable for outer chassis and interior chassis.
・UL flame-retardant 5VA acquisition and low specific gravity that contribute to product miniaturization and weight reduction.
・Heat resistance
・Acid and alkali resistance.

Cash dispenser

Chassis, internal chassis, conductive mechanism parts

Products

XYRON™

Grades

X8610
・ Gives conductivity
・ Excellent mechanical properties (strength / rigidity)
・ High heat resistance

Features

・A material with a high degree of freedom in design suitable for chassis, internal chassis, and conductive mechanism parts.
・Since it suppresses the generation of static electricity, it is a suitable material for energized parts.

Solar cell junction box

The box shape parts that houses a diode of a solar panel

Products

XYRON™

Grades

540Z 644Z PV41Z
・Tracking resistance
・Hydrolysis resistance
・Acid and alkaline resistance
・Small dimensional change under high temperature and high humidity

Features

・Excellent heat resistance, rigidity, and low water absorption.
・Small dimensional change under high temperature and high humidity

solar cell connecter

Connector between cable and junction box of solar cell.

As Asahi Kasei Group Environmental Contribution Products, this product contributes to the reduction of CO2 emissions at the stage of use.

Products

XYRON™

Grades

PV40Z
・Tracking resistance
・Hydrolysis resistance
・Acid and alkaline resistance
・Long-term stability of physical properties

Features

・Excellent balance between tracking resistance and low temperature impact strength.
・Enable to design compact high voltage compatible connector.
・It has excellent hydrolysis and ammonia resistance, and does not cause an extreme deterioration of physical properties even under a high temperature and high humidity.

Water mixing tap

Internal parts of the mixing tap

Products

XYRON™

Grades

WG720, WG722
(GF reinforced/drinking water contact grade)
・Excellent heat resistance, hydrolysis resistance, and excellent vibration fatigue characteristics.
・Excellent acid and alkali resistance.

Features

・Achieves rust prevention by resinizing the parts around the mixing tap
・Our materials are also suitable for parts which need strength.
・Contributes to weight reduction and cost performance due to low specific gravity.
・Complies with the standards for drinking water contact materials (NSF 61, etc.).

Water purification parts

Water purification system related parts (case, cap, and etc.)

Products

XYRON™

Grades

WG731
(GF reinforced/drinking water contact grade)
・Excellent heat resistance, hydrolysis resistance, and excellent vibration fatigue characteristics.
・Excellent acid and alkali resistance.
・Excellent dimensional accuracy and weldability.

Features

・Achieves rust prevention by resinizing water supply and drainage parts.
・ Our materials are also suitable for parts which need strength.
・Contributes to weight reduction and cost performance due to low specific gravity.
・Complies with the standards for drinking water contact materials (NSF 61, etc.).

Printer mechanism parts
(XYRON™)

Printer housing, mechanical parts for laser beam printer (LBP), inkjet printer (IJP)

Products

XYRON™

Grades

・X7744, X444V, X523V, X364V: Filler reinforced materials.
Ultra-low warpage, high dimensional stability, low specific gravity, high rigidity, non-halo flame retardancy, and a wide range of heat resistant temperatures which can be designed.
・CN51V: Light transmitting material. 940nm infrared transmission.
・VT31V, VT31Z, VT52Z: Vibration damping material. Help achieve noise reduction of parts.
・DG040, DG235, DG141 (PPS/PPE blends): Chemical resistance, low warpage, high dimensional stability, high heat resistance, good flow, and high stiffness

Features

・Can be used for high-precision parts with design flexibility, which is suitable for chassis and mechanical parts.
・Light transmitting material contributes adhesive-free design.
・Some grades have high loss coefficient and vibration suppression effect.
・Some grades have high chemical resistance.
・DG series are suitable for high-precision parts, and also it contributes to the miniaturization of parts.
・Small specific gravity contributes to the weight reduction of parts.

Fan impeller for high speed fan motor

Cooling fan for servers, personal computers and other equipment

Products

XYRON™

Grades

G793Z、G702V、G601Z
・GF Reinforced grades
・GF content 10%, 20% and 30%

Features

・Since our materials have low specific gravity, they will help achieve weight reduction and contribute to high rotation.
・Low dimensional change due to low water absorption characterestic.
・Small deformation under high temperature due to high heat resistance.
・Suitable for high-speed fans and processed components that require strength.
・Can achieve cost reduction by using our materials to make components lighter and smaller.

・Communication base station antenna cover
・Base materialof MID

Covers for various communication antennas and base materials for MID antennas

Products

XYRON™

Grades

442Z、Development grade
・Non-reinforced flame-retardant grades

Features

・The excellent dielectric performance (low dielectric constant, low dissipation factor, and their small temperature dependence) make our materials suitable for using as antenna cover.
・There is a lineup of grades with various dielectric performances such as high dielectric constant development materials.
・Good impact resistance and stable long-term physical properties.

Nickel metal hydride battery cell case

As Asahi Kasei Group Environmental Contribution Products, this product contributes to the reduction of CO2 emissions at the stage of use.

nimh

Products

XYRON™

Grades

Xyron™ Excellent Lightweight Grade
・Lightweight (low specific gravity)
・ Alkaline resistance
・Gas barrier
・Metal degradation resistance

Features

This material was developed to achieve lightweight and the various requirements for battery cell case.

Inter-cell spacer

Insulator between battery cells.

Products

XYRON™

Grades

T series and 340Z
・Tracking resistance
・Hydrolysis resistance
・Acid and alkaline resistance
・Stable long-term physical properties

Features

・A material with a high degree of freedom in design suitable for the housing.
・A low specific gravity material with excellent creep characteristic, non-halogenated flame retardancy, and dimensional stability.
・Excellent thin-wall moldability, contributing to space saving and weight reduction.

Bus bar cover

Cover of conductor through which high voltage and large current flows.

Products

XYRON™

Grades

TF701, TA720, X9110

Features

・Thin-wall moldability, insulation, and heat resistance.
・Some grades have oil resistance. Easy to handle.

Fuel cell

Components for fuel cells

Products

XYRON™

Grades

500H
・Non-reinforced heat resistant grade
・Low elution performance
・Acid resistance

Features

・Low elution from resin (ions, oligomers, and etc.) to water
which is highly evaluated by customers.
・Excellent hot water resistance and acid resistance, and physical properties hardly deteriorate even when components are immersed for a long period of time.

In-vehicle camera
(lens barrel, lens spacer)

Lens barrels and lens spacers used in various cameras installed in cars

Products

XYRON™

Grades

・XP640 PPA/PPE blend + GF40%
・DG040, DG340 PPS/PPE blend + special glass filler 40%

Features

・Demonstrate high heat resistance, high strength, and high stiffness performance comparable to high heat resistance PA.
・Suppress the decrease in mechanical strength under high temperature, and reduces anisotropy of dimensional change by blending special glass filler.
・ Contribute to cost reduction of metal components by resinification.

Head-up display

Head-up display components installed in cars

Products

XYRON™

Grades

・ DG040 PPS/PPE blend + special glass filler 40%
・ 744Z PPE/PS blend (Non-reinforced)

Features

・By blending PPE with PPS, dimensional stability at high temperatures is improved, and by blending special glass filler, dimensional anisotropy is reduced.
・UL flame retardancy V-0, deflection temperature under load 135 °C, excellent balance of heat resistance, toughness and dimensional stability.

Relay block / junction box (XYRON™)

Storage case for relays, fuses, etc.

Products

XYRON™

Grades

A0210 (PA / PPE blend):. High heat resistance, high toughness, low water absorption kow dimensional change (compared to nylon material)
A0230: A0210 equivalent grade, which is using localized raw materials in the ASEAN region .
AF700 (PA / PPE blend): High heat resistance, low water absorption low dimensional change, and UL V-0

Features

-Improve changes in water absorption dimensions while maintaining the excellent heat resistance and toughness of PA.
-Can be used for advanced designs that require toughness due to our materials' strength and high toughness characterestics.
・ UL V-0 grade is also available.
-By producing hexamethylenediamine, which is the raw material for PA, in-house (the only Japanese company), we have achieved stable supply and high quality.
・ By localizing raw materials overseas, we maintain a stable supply and cost globally.

Inverter cover

Covers of various electrical equipments

Products

XYRON™

Grades

240Z、440Z
・Non-reinforced and flame retardant grades
・Excellent electrical characteristics and flame retardancy
・Hydrolysis resistance

Features

・Material with design flexibility suitable for outer chassis and interior chassis.
・UL flame-retardant 5VA acquisition and low specific gravity that contribute to product miniaturization and weight reduction.
・Heat resistance
・Acid and alkali resistance.

Cash dispenser

Chassis, internal chassis, conductive mechanism parts

Products

XYRON™

Grades

X8610
・ Gives conductivity
・ Excellent mechanical properties (strength / rigidity)
・ High heat resistance

Features

・A material with a high degree of freedom in design suitable for chassis, internal chassis, and conductive mechanism parts.
・Since it suppresses the generation of static electricity, it is a suitable material for energized parts.

Solar cell junction box

The box shape parts that houses a diode of a solar panel

Products

XYRON™

Grades

540Z 644Z PV41Z
・Tracking resistance
・Hydrolysis resistance
・Acid and alkaline resistance
・Small dimensional change under high temperature and high humidity

Features

・Excellent heat resistance, rigidity, and low water absorption.
・Small dimensional change under high temperature and high humidity

solar cell connecter

Connector between cable and junction box of solar cell.

As Asahi Kasei Group Environmental Contribution Products, this product contributes to the reduction of CO2 emissions at the stage of use.

Products

XYRON™

Grades

PV40Z
・Tracking resistance
・Hydrolysis resistance
・Acid and alkaline resistance
・Long-term stability of physical properties

Features

・Excellent balance between tracking resistance and low temperature impact strength.
・Enable to design compact high voltage compatible connector.
・It has excellent hydrolysis and ammonia resistance, and does not cause an extreme deterioration of physical properties even under a high temperature and high humidity.

Water mixing tap

Internal parts of the mixing tap

Products

XYRON™

Grades

WG720, WG722
(GF reinforced/drinking water contact grade)
・Excellent heat resistance, hydrolysis resistance, and excellent vibration fatigue characteristics.
・Excellent acid and alkali resistance.

Features

・Achieves rust prevention by resinizing the parts around the mixing tap
・Our materials are also suitable for parts which need strength.
・Contributes to weight reduction and cost performance due to low specific gravity.
・Complies with the standards for drinking water contact materials (NSF 61, etc.).

Water purification parts

Water purification system related parts (case, cap, and etc.)

Products

XYRON™

Grades

WG731
(GF reinforced/drinking water contact grade)
・Excellent heat resistance, hydrolysis resistance, and excellent vibration fatigue characteristics.
・Excellent acid and alkali resistance.
・Excellent dimensional accuracy and weldability.

Features

・Achieves rust prevention by resinizing water supply and drainage parts.
・ Our materials are also suitable for parts which need strength.
・Contributes to weight reduction and cost performance due to low specific gravity.
・Complies with the standards for drinking water contact materials (NSF 61, etc.).

Printer mechanism parts
(XYRON™)

Printer housing, mechanical parts for laser beam printer (LBP), inkjet printer (IJP)

Products

XYRON™

Grades

・X7744, X444V, X523V, X364V: Filler reinforced materials.
Ultra-low warpage, high dimensional stability, low specific gravity, high rigidity, non-halo flame retardancy, and a wide range of heat resistant temperatures which can be designed.
・CN51V: Light transmitting material. 940nm infrared transmission.
・VT31V, VT31Z, VT52Z: Vibration damping material. Help achieve noise reduction of parts.
・DG040, DG235, DG141 (PPS/PPE blends): Chemical resistance, low warpage, high dimensional stability, high heat resistance, good flow, and high stiffness

Features

・Can be used for high-precision parts with design flexibility, which is suitable for chassis and mechanical parts.
・Light transmitting material contributes adhesive-free design.
・Some grades have high loss coefficient and vibration suppression effect.
・Some grades have high chemical resistance.
・DG series are suitable for high-precision parts, and also it contributes to the miniaturization of parts.
・Small specific gravity contributes to the weight reduction of parts.

Fan impeller for high speed fan motor

Cooling fan for servers, personal computers and other equipment

Products

XYRON™

Grades

G793Z、G702V、G601Z
・GF Reinforced grades
・GF content 10%, 20% and 30%

Features

・Since our materials have low specific gravity, they will help achieve weight reduction and contribute to high rotation.
・Low dimensional change due to low water absorption characterestic.
・Small deformation under high temperature due to high heat resistance.
・Suitable for high-speed fans and processed components that require strength.
・Can achieve cost reduction by using our materials to make components lighter and smaller.

・Communication base station antenna cover
・Base materialof MID

Covers for various communication antennas and base materials for MID antennas

Products

XYRON™

Grades

442Z、Development grade
・Non-reinforced flame-retardant grades

Features

・The excellent dielectric performance (low dielectric constant, low dissipation factor, and their small temperature dependence) make our materials suitable for using as antenna cover.
・There is a lineup of grades with various dielectric performances such as high dielectric constant development materials.
・Good impact resistance and stable long-term physical properties.

Nickel metal hydride battery cell case

As Asahi Kasei Group Environmental Contribution Products, this product contributes to the reduction of CO2 emissions at the stage of use.

nimh

Products

XYRON™

Grades

Xyron™ Excellent Lightweight Grade
・Lightweight (low specific gravity)
・ Alkaline resistance
・Gas barrier
・Metal degradation resistance

Features

This material was developed to achieve lightweight and the various requirements for battery cell case.
